In-Circuit Tester (ICT)

Request Demo Watch(1'49")

We redesigned traditional bed-of-nails testers to fit modern needs for quick in-circuit testing!

Standardize

Frustrated with the bulky and unsustainable nature of traditional ICT fixtures, we began by designing a standardized ICT fixture base. The new standardized base is sleek, sturdy, and reusable.

Customized Pin Alignment

To customize our ICT solution to meet the needs of our clients’ unique PCB iterations, we replaced the traditional bed-of-nails with custom Pogo Pin Cassettes (PPC). PPC are designed to be swiftly built then inserted into the ICT fixture base.

Complement

Our in-circuit testers are programmable with the PLT, our proprietary test automation computer. The ICT makes physical contact with finished printed circuit boards (PCBA) to test for the following: Power and Relays, Electrical Measurements, Logic Measurements, UART Testing, and CAN Bus Testing

Note: our proprietary ICT solution requires a PLT.


Order Your Custom ICT Solution

In-Circuit Tester - Chassis
In-Circuit Tester - Chassis
In-Circuit Tester - Chassis
Step 1: The ICT Fixture Base
The ICT-100A is a box with vertical arms supporting a toggle clamp.
To perform in-circuit testing on a customized Printed Circuit Board (PCB), the ICT-100A hosts a custom-built Pogo Pin Cassette (PPC).
All ICT related products are built by engineers based in our Shenzhen lab, as such our shipping policy for this product is DDU, meaning shipping costs will be charged after the fact.
Contact your Account Manager for more info or read more about how we developed this ICT solution here.

Shipping Policy:
DDU with customer's shipping account number from Shenzhen.
In-Circuit Tester - Pogo Pin Cassette
Step 2: The Pogo Pin Cassette (PPC)
Each PPC is custom-built to be compatible for a Device Under Testing (DUT) specified by the client. Additionally, each PPC comes with a custom pressing plate.
All PPC are built by engineers based in our Shenzhen lab, as such our shipping policy for this product is DDU, meaning shipping costs will be charged after the fact.
Contact an account manager to learn more!

Shipping Policy:
DDU with customer's shipping account number from Shenzhen.

1

Upload
PCB CAD

2

Confirm Test
Point Matrix

3

Build and
Ship PPC
