The 2nd generation of Production Line Tool designed for Linux device programming and testing

Program your Linux or 32-bit device - use JTAG, SWD, UART, USB or directly flash microSD cards, verified support for loads of MCU targets.

Programmable power to your device under test (1.8V, 3.3V, 5V, variable up to 24V).

Digital multimeter (DMM) functionality controlled by software.

Production Line Tool for Linux (added on 9/16)

Aircraft-grade aluminum enclosure - tough, lightweight, and highly recyclable.

PLT-OS is hardened Linux distribution, purpose built for the production line.

Secure connection to your cloud backend via PLTcloud.

Simple

iF Design Award - Manufacturing is not easy and we designed the PLT-300A to be intuitive for the line manager setting it up and the operator using it, wherever they may be on the planet. Our efforts were recognized with a product design award from iF.

Secure

Blue Clover is a member of the ioXt Alliance and are in the process of certifying the PLT-300A.

Sustainable

Climate Neutral - Through our support of Climate Neutral we measure, reduce, and offset all carbon emitted to make PLTs and maintain the PLTcloud backend. We are working hard to reduce the environmental cost of all electronic devices with the 10 ways outlined in our Better Devices Manifesto. The PLT-300A relieves pressure to send engineers to distant production site for setup and troubleshooting.

General Specification

Features

Programmable power supply to 24V
Program MCUs via JTAG,SWD, UART, USB
Micro SD card flasher
Measure voltage, current, resistance, capacitance
UART communication
BLE Low-Level(LL) and GATT commands
CAN bus communication
1 TB solid-state drive (SSD)
Cloud-based firmware deployment
Automated cloud reports
Barcode scanner support
NFC tag writer support
Label printer support
HDMI display port

Applications

Firmware programming
Device provisioning
In-circuit testing
Finished goods testing
Production logging

Power

Input power: 100~240VAC,50-60Hz
Supply Voltages: 1.8V,3.3V, SV, Variable 1.5~24V(up to 2A each)

Electrical Measurements

The PLT-300A can connect with up to 45 analog test points (13 are directly connected to the multimeter circuit and the rest are routed through MUX circuits to the multimeter).

Measurement	Range	Accuracy
Voltage	-10V~10V	+/-5%
Current	0.2μA~2A	+/-5%
Resistance	0.1Ω~60MΩ	+/-4%
Capacitance	1pF~66mF	+/-5%
Frequency	0.1Hz~66MHz	+/-2%

Firmware Programming

ESP32
nRF52
nRF91
STM32

Comprehensive supported microcontroller list can be found in the PLT Support Center(plt.bcdevices.com).

Logic Measurements

The PLT-300A can connect with up to 48 digital test points (15 are directly connected to the internal processors and the rest are routed through MUX circuits).

UART Testing

2 UART channels
Speed: 300bps ~ 1Mbps
Flow control: Xon/Xoff, DTR/CTS

Supported Label Printers

Zebra GX430t
Zebra QLn220

Refer to PLT Support Center（plt.bcdevices.com) for a complete list of supported label printers.

Rear Connectors

AC Power - IEC 320 C13
SWD - 6-pin TC2030-IDC
DUT Power - 8-pin Molex Micro-Fit
DUT Signal - HD78
DUT USB - USB-C
CAN bus - 2x wire terminal
USB Peripherals - 4x USB-A
Ethernet - RJ45 Cat6a
Display - HDMI

CAN Bus Testing

CAN Bus standards are supported by the PLT-300A:

CAN 2.0A	11-bit
CAN 2.08	29-bit
IS0-11898-1	-
IS0-11898-2	1Mbps
IS0-11898-3	40kbps - 125kbps
IS0-11898-4	-
IS0-11898-5	1Mbps
IS0-11898-6	1Mbps

IMPORTANT NOTE: Additional test points and test capabilities can be accommodated via customized pogo pin cassettes.

Security

PLT-300A includes a Secure Element to protect the integrity of the connection with PLTCloud. All communication with PLTcloud, including the deployment of firmware and reporting of test results, are protected using TLS1.2 mutual authentication.

Supported Scanners

Zebra (Symbol) LS2208 (1D)
Zebra (Symbol) LS4208 (1D)
Zebra (Symbol) DS2208 (2D) Micro-Fit
Zebra (Symbol) DS6708 (2D)
Zebra (Symbol) DS8108 (2D)

Refer to the PLT Support Center (plt.bcdevices.com) for a complete list of supported scanners.

Dimensions & Weight

2U format for rack mounting
355mm x 251mm x 87mm (feet add 14mm to the height)
3.2 kg (4.7 kg with cables and packaging)

Front Connectors

USB Peripherals - 2x USB-A
SD Card - microSD push-push slot

Packaging

Package includes PLT-300A, AC power cord，Cat6 ethernet cable.
